Dreambox DM 500 HD
Opis
Ten produkt nie jest już dostępny - zobacz inne tunery satelitarne
Odbiornik Dreambox DM 500 HD to najwyższej klasy odbiornik satelitarny HD przeznaczony dla najbardziej wymagających klientów. Nieograniczone możliwości modyfikacji tego tunera, bardzo duża liczba różnego rodzaju oprogramowania alternatYwnego powoduje, że Dreambox to marka nr 1 wsród pasjonatów telewizji satelitarnej.
Cechy produktu :
- Linux Operating System
- 2 LED status
- MPEG-2 / H.264 Hardware decoding
- Tuner: DVB-S2
- 1 x Smartcard-Reader (Dreamcrypt CA)
- eSATA
- Mini USB, Service
- 10/100Mbit Ethernet Interface
- 1 x Scart (RGB, FBAS or S-Video)
- HDMI
- analog modem
- S/PDIF Interface for digital bit stream out (AC-3)
- 64 MByte Flash, 256 MByte RAM
- unlimited channel lists for TV/Radio
- channel-change time < 1 second
- automatic service scan
- directly bouquet-lists
- EPG (electronic program guide)
- multiple LNB-Switching control (supports DiSEqC)
- OSD in many languages and skin-support
- Videotext Decoder
- extern 12V power supply
Dane techniczne:
DBS-Tuner, DVB-S2:
Frequency Range 950 .... 2150 MHz
Demodulation DVB-S (QPSK); DVB-S2 (8PSK,QPSK)
Symbol rate DVB-S: 2 ... 45 Mbaud/s, SCPC/ MCPC
DVB-S2: 10 – 31 Mbaud/s (8PSK) , 10 –30 Mbaud/s (QPSK)
Video decoder:
Video Compression MPEG-4,MPEG-2 and MPEG-1 compatible, H.246
Video Formats 4:3 / 16:9
Letterbox for 4:3 TV-Device
Audio decoder:
Audiokompression MPEG-1 & MPEG-2 Layer I and II, MP3
Audio Mode Dual (main/sub), Stereo
Frequency: 32 kHz, 44.1 kHz, 48 kHz, 16 kHz, 22.05 kHz, 24 kHz
Output analog:
Output Level L/R 0,5 Vss on 600 Ohm
THD > 60 dB (1 kHz)
Crosstalk < -65 dB
Output digital:
Output Level 0,5 Vss on 75 Ohm
Sampled Data Filtering 32 kHz, 44.1 kHz, 48 kHz
S/PDIF-Output optical, Toslink
Video parameter:
Input Level FBAS 1 Vss +/- 0.3 dB on 75 Ohm
Teletext filter in conformity with ETS 300 472 Standard
TV-Scart:
Output: FBAS, RGB, S-Video
MiniUSB service connector
Function: Update of Firmware
Ethernet:
10/100 MBit compatible interface
Function: Update of Firmware
Analoge modem:
analoge modem for Internet connection
LNB power and polarisation per tuner:
LNB Current 500mA max.; short-circuit-protected
LNB Voltage vertical < 14V no load, > 11,5V at 400mA
LNB Voltage horizontal < 20V no load, > 17,3V at 400mA
Count of active satellite position:
DiSEqC 1.0/1.1/1.2 and USALS - Rotor Control
Power consumption:
< 12W at 12V in operation
< 1W in standby
External PSU
Input:
110-240V AC / 50-60Hz / 0,6A
Output:
12V = / 3,0A
Physical specification:
Ambient Temperature +15°C...+35°C
Humidity < 80%
Size (W x D x H): 195 mm x 130 mm x 40 mm
Weight: 0,7 kg without HDD
gwarancja :
24miesiące
Tuner pochodzi z polskiej sieci dystrybucyjnej!
Kupując u nas zaoszczędzisz sobie problemów w razie kłopotów z tunerem!
Nie daj się skusić niską ceną!
